    18.5-Inch Linux Display for Medical Devices and Public Terminals

    Ask Lasest Price
    Brand Name : ZXTLCD
    Model Number : ZXTLCD-E185BLWFS
    Certification : CE/Rohs/FCC
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 2000 pcs per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    18.5-Inch Linux Display for Medical Devices and Public Terminals

    18.5-Inch Linux Display for Medical Devices and Public Terminals

    The 18.5-inch Linux display is an ideal choice for medical devices, offering a reliable and high-quality interface for displaying critical health data and patient information. With its 1920 x 1080 resolution and 72% NTSC color gamut, it provides clear and detailed visuals necessary for precise medical diagnostics and monitoring. This screen can be easily integrated into patient monitoring systems, ECG machines, and radiology equipment, delivering real-time updates with sharp contrast and brightness levels (250 cd/m²). Its 1200:1 contrast ratio ensures excellent clarity of both bright and dark details, making it suitable for environments where accurate and legible information is paramount.

    LCD Panel ParametersScreen Size18.5 Inch
    Display Area411.3 mm.(Height) X 231.4(Width)mm.
    Aspect Ratio16 : 9
    LCD Typea-Si TFT-LCD Monitor
    Maximum Resolution1920 X 1080
    Display Color16.7m , 72% NTSC
    Brightness250cd/
    Contrast Ratio1200 : 1
    Viewing Angle (Up/Down/Left/Right)89°/89°/89°/89° (Type)(CR≥10)
    Response Time14ms
    LCD Panel Lifespan (Hours)60,000(Hour.)
    Field Frequency60Hertz
    Audio parametersAudio systemStereo
    Speaker size≈ 99 x 45 x 20 mm
    Impedance8 Ohm
    Power2 x 5 Watt
    Loudness> 80 Decibel
    Interface4-pin connector
    Internal computer configuration
    (Choose one of two)
    CPUIntel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHzIntel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
    Graphics CardIntegrated Graphics Card Intel® HD 4600Integrated Graphics Card Intel® HD 530
    RAM4GB8GB
    Storage Memory Capacity128GB256GB
    OSLinuxLinux
    Wi-Fi Built-inSpeed 150Mbps 802.11n wifi IntegratedSpeed 150Mbps 802.11n wifi Integrated
    Media FormatVideo Formatwmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
    Audio FormatMP3, WMA
    Photo FormatBMP, JPEG, PNG, GIF etc.
    Onboard InterfaceNetwork portRJ45 X 1, 10M/100M Adjustable Ethernet
    HDMI1
    USB4
    PowerPower SupplyAlternating Current 100V~240V, 50/60Hz
    Maximum Power Loss≤ 30 Watt
    Standby Mode Power Loss< 1 Watt
    FeaturesOperating Temperature0 ~ 50
    Storage TemperatureBelow 10 ~ +60
    Package SizeDevice Dimensions460 X 280 X 50.7mm
    Net Weight6.5 Kilogram
    Package Size51 X 33.5 X 11Centimeter
    Gross Package Weight per Unit7 Kilogram

    In addition to medical settings, this 18.5-inch screen excels in public terminals such as information kiosks or self-service stations in high-traffic areas like shopping malls, airports, or train stations. The display's robust build and wide viewing angles (89°/89°/89°/89°) make it a valuable asset for places where customers or visitors need easy access to information from various perspectives. Whether displaying wayfinding maps, event schedules, or public announcements, it ensures that content is always visible and engaging to the audience, even in busy, dynamic environments.

    18.5-Inch Linux Display for Medical Devices and Public Terminals

    18.5-Inch Linux Display for Medical Devices and Public Terminals18.5-Inch Linux Display for Medical Devices and Public Terminals18.5-Inch Linux Display for Medical Devices and Public Terminals18.5-Inch Linux Display for Medical Devices and Public Terminals
    The Linux-based screen is also highly versatile for interactive applications in both public and professional contexts. It can be deployed in queue management systems, where it displays wait times or customer numbers, or integrated into digital signage for broadcasting multimedia content such as advertisements, corporate messages, or news updates. Its Wi-Fi connectivity and USB ports ensure seamless content updates, making it an effective solution for businesses that need flexible, easy-to-manage displays. Moreover, the screen's low power consumption (≤ 30 watts) ensures energy efficiency, making it a cost-effective option for long-term operations in settings like lobbies, waiting areas, or customer feedback stations.
