    19-Inch Windows Screen for Transportation Systems and Access Control Panels

    Ask Lasest Price
    Brand Name : ZXTLCD
    Model Number : ZXTLCD-E190BPWFS
    Certification : CE/Rohs/FCC
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 2000 pcs per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    19-Inch Windows Screen for Transportation Systems and Access Control Panels

    19-Inch Windows Screen for Transportation Systems and Access Control Panels

    The 19-inch Windows display offers an ideal solution for transportation systems that require robust, high-quality visuals for a variety of operational tasks. Whether used for real-time train or bus schedules, ticketing kiosks, or passenger information systems, this screen delivers sharp visuals with its 1280 x 1024 resolution and high contrast ratio of 1000:1. This is essential for maintaining clarity in public spaces where environmental lighting can vary. The wide viewing angles ensure that passengers can easily read information, whether standing or sitting. Furthermore, the integrated Wi-Fi allows for seamless content updates, making it a reliable choice for digital signage that must be updated frequently with real-time information.


    LCD Panel ParametersScreen Size19 Inch
    Display Area376.32 mm.(Height) X 301.06(Width)mm.
    Aspect Ratio4 : 3
    LCD Typea-Si TFT-LCD Monitor
    Maximum Resolution1280 X 1024
    Display Color16.7m , 73% NTSC
    Brightness250cd/
    Contrast Ratio1000 : 1
    Viewing Angle (Up/Down/Left/Right)89°/89°/89°/89° (Type)(CR≥10)
    Response Time14ms
    LCD Panel Lifespan (Hours)60,000(Hour.)
    Field Frequency60Hertz
    Audio parametersAudio systemStereo
    Speaker size≈ 99 x 45 x 20 mm
    Impedance8 Ohm
    Power2 x 5 Watt
    Loudness> 80 Decibel
    Interface4-pin connector
    Internal computer configuration
    (Choose one of two)
    CPUIntel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHzIntel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
    Graphics CardIntegrated Graphics Card Intel® HD 4600Integrated Graphics Card Intel® HD 530
    RAM4GB8GB
    Storage Memory Capacity128GB256GB
    OSWin10 or win11 OptionalWin10 or win11 Optional
    Wi-Fi Built-inSpeed 150Mbps 802.11n wifi IntegratedSpeed 150Mbps 802.11n wifi Integrated
    Media FormatVideo Formatwmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
    Audio FormatMP3, WMA
    Photo FormatBMP, JPEG, PNG, GIF etc.
    Onboard InterfaceNetwork portRJ45 X 1, 10M/100M Adjustable Ethernet
    HDMI1
    USB4
    PowerPower SupplyAlternating Current 100V~240V, 50/60Hz
    Maximum Power Loss≤ 30 Watt
    Standby Mode Power Loss< 1 Watt
    FeaturesOperating Temperature0 ~ 50
    Storage TemperatureBelow 10 ~ +60
    Package SizeDevice Dimensions416 X 344 X 55.7mm.
    Net Weight6.5 Kilogram
    Package Size50 X 42 X 15Centimeter
    Gross Package Weight per Unit7 Kilogram

    In access control panels, the 19-inch monitor provides secure and reliable visual interfaces for authentication systems like keycard access, biometric verification, and secure building entry. With its customizable display options, it supports a range of applications, from security monitoring to door control systems in corporate offices, airports, and data centers. The user-friendly interface, coupled with its compatibility with Windows-based software, makes it an excellent choice for smart building systems that require secure, interactive screens for user input, security alerts, and status updates.

    19-Inch Windows Screen for Transportation Systems and Access Control Panels

    19-Inch Windows Screen for Transportation Systems and Access Control Panels19-Inch Windows Screen for Transportation Systems and Access Control Panels19-Inch Windows Screen for Transportation Systems and Access Control Panels19-Inch Windows Screen for Transportation Systems and Access Control Panels

    In addition to security and transportation applications, this 19-inch screen is well-suited for integration into industrial automation systems. Whether it's used as a control panel for machinery, a monitor for real-time production data, or as part of asset tracking systems in warehouses and factories, the display ensures clear, easy-to-read data in demanding environments. The low power consumption and long lifespan of this screen make it perfect for systems that operate 24/7. Its enhanced graphics capabilities allow operators to monitor system performance and handle maintenance tasks with ease, making it a key component in ensuring smooth operations across industries such as logistics, manufacturing, and inventory management.
