    15-Inch Embedded Monitor for Security Systems, Transportation Displays, Process Monitoring, and Public Information Panels

    Ask Lasest Price
    Model Number : ZXTLCD-RM150SM
    Certification : CE/Rohs/FCC
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 2000 pcs per month
    Delivery Time : 3-5 working days
    Brand Name : ZXTLCD
    • Product Details
    • Company Profile

    15-Inch Embedded Monitor for Security Systems, Transportation Displays, Process Monitoring, and Public Information Panels

    15-Inch Embedded Monitor for Security Systems, Transportation Displays, Process Monitoring, and Public Information Panels

    A New Partner in the Smart Automotive Field, the 15-inch Embedded Industrial Control All-in-One Machine Supports Future Mobility


    With the rapid development of smart automotive technology, the demand for high-performance and stable control systems is growing. The 15-inch embedded industrial control all-in-one machine is designed specifically for the smart automotive field, providing a comprehensive control solution that is non-touch but fully functional.

    15-Inch Embedded Monitor for Security Systems, Transportation Displays, Process Monitoring, and Public Information Panels

    15-inch Embedded Industrial Control All-in-One Machine: Stable and Reliable, Navigating Complex In-Vehicle Environments

    In the field of smart vehicles, the stability and reliability of onboard systems are crucial. The 15-inch embedded industrial control all-in-one machine, with its outstanding performance and durable design, can maintain stable operation even in environments with frequent vibrations and temperature fluctuations, ensuring smooth operation of onboard systems and providing drivers with a reassuring travel experience.

    LCD Panel ParametersScreen Size15 Inch
    Display Area304.2 mm.(Height) X 228(Width)mm.
    Aspect Ratio16 : 9
    LCD Typea-Si TFT-LCD Monitor
    Maximum Resolution1024 X 768
    Display Color262K/16.2M , 72% NTSC
    Brightness300cd/
    Contrast Ratio1500 : 1
    Viewing Angle (Up/Down/Left/Right)89°/89°/89°/89° (Type)(CR≥10)
    Response Time15ms
    LCD Panel Lifespan (Hours)60,000(Hour.)
    Field Frequency60Hertz
    Audio Parameters
    (External Speaker Option)
    Audio systemStereo
    Speaker size≈ 99 x 45 x 20 mm
    Impedance8 Ohm
    Power2 x 5 Watt
    Loudness> 80 Decibel
    Interface4-pin connector
    Onboard InterfaceHDMI Input1
    VGA Input1
    DVI Input1
    USB Type B or any desired USB Type1
    PowerPower SupplyAlternating Current 100V~240V, 50/60Hz
    Maximum Power Loss≤ 25 Watt
    Standby Mode Power Loss< 1 Watt
    FeaturesOperating Temperature0 ~ 50
    Storage TemperatureBelow 10 ~ +60
    AccessoriesPower Cord Length1.5m
    HDMI Cable Length2m
    USB-A to USB-B Cable Length1.5m
    Stereo Speaker Size with Connector99*45*20mm
    Stereo Speaker Length1.5m
    Package SizeDevice Dimensions351 X 275X 51.7mm.
    Net Weight5 Kilogram
    Package Size41.2 X 34 X 11Centimeter
    Gross Package Weight per Unit5.5 Kilogram

    15-Inch Embedded Monitor for Security Systems, Transportation Displays, Process Monitoring, and Public Information Panels

    15-inch Industrial Control Panel All-in-One Machine: Clear Display, Optimized Driving Information Interaction

    At the same time, the 15-inch industrial control panel all-in-one machine plays a core role in information interaction within smart vehicles. It is equipped with a high-resolution display that can clearly present navigation, vehicle status, entertainment information, etc., optimizing the flow of information between the driver and the vehicle, thereby enhancing the driving experience.

    15-Inch Embedded Monitor for Security Systems, Transportation Displays, Process Monitoring, and Public Information Panels

    The 15-inch embedded industrial control all-in-one machine and the 15-inch industrial control panel all-in-one machine, with their stable and reliable performance and clear display effect, are becoming indispensable components in the field of smart automobiles. They not only enhance the driving experience but also promote the advancement of the smart automobile industry. In the future, with the continuous progress of technology, they will play an even greater role in the field of smart automobiles.
