28.6 inch Ultra Wide Stretched Bar LCD Monitor Commercial Screen
shelf edge display stretched lcd display
Product Advantage:
1), The stretched LCD display board support the object-based format
to provide visitor information with high visibility and
intelligibility. The screen video, message, graphics can be
displayed in different ways.
2), An advantage of widescreen LCD display units, it can display
the temperature weather&date and advertising video, graphics
real-time.
3), 7*24*365 hours working.
4), The right message at the right time: Support WIFI, 3G, LAN,
Signage Administrator, Mobile App
5), Android Network Digital Signage
| The specification |
| Model No | Product model | ZXTLCD-BAR286HMJ |
| LCD Screen Panel | Screen size | 28.6" LCD Panel |
| Active display area | 698.4(H) X 196.43(V)mm |
| Resolution | 1920(V) X 540(H) |
| Brightness | 400cd/m2 |
| Contrast ratio | 1200:1 |
| Display color | 16.7M |
| Backlight type | WLED |
| Viewing angles | 89°/89°/89°/89°(U/D/L/R) |
| Response time | 8ms |
| Lifespan | 50000 hours |
| Main board | CPU | Rockchip PX30 Quad core ARM Cotex-A35 |
| RAM | 1G DDR3(1 G/2G for optional ) |
| ROM | 8G EMMC(8G/16G/32G/64GEMMC for optional) |
| Memory extension | TF Card extension with the highest support for 64GB |
| System | Android 8.1 |
| Internet | Support 2.4G WIFI connection |
| RTC real time clock | Support timing on / off function |
| Interfaces | 1xTF card slot |
| 1*micro USB(OTG) |
| 1*Type-c(DC 12V input,Need to match with our company's special
adapter for power supply) |
| External function optional | 4G module |
| 8Ω1WX1 speaker |
| Support special requirements customization |
| machine specification | Operating voltage | 100-240V(50/60Hz) |
| Power consumption | ≤30W |
| Product size | 733.5(H)X235(V)X51(D)mm |
| Installation | wall-mounted |
| Apperance material | Metal shell |
| Net weight | ≤4.8KG |
| Surface treatment | Black metal paint |
| Environmental | Storage Environment | Temperature:-20℃～60℃ |
| Humidity:5%～95% |
| Atmospheric Pressure:86kPa～104kPa |
| Working Environment | Temperature:0℃～45℃ |
| Humidity:10%～85% |
| Atmospheric Pressure:86KPa～104KPa |
| Packing list | Bar lcd display | 1pcs |
| OTG Cable | 1Pcs(OTG cable,micro USB to USB 2.0) |
| Adapter | 1Pcs (12V, 2A) |
| Support special requirements customization |
Trend of New Retail Info Display
Smart retail uses commercial screen as display terminal to create
scene marketing. Through the use of various intelligent means and
big data analysis to influence consumers. With the rise of smart
retail, commercial display plays an increasingly important role in
retail window, interior decoration and other fields.
Traditional shopping malls will display a wide variety of goods for
consumers to choose, and consumers will always make goods messy
because of touching and fiddling. With the arrival of smart retail,
commercial screen has become the catalyst of human- screen
interaction, and consumers can complete data matching of goods and
virtual try- on of clothes and shoes by touching it lightly.
Supermarkets are full of a whole variety of different products, and
you’ll also notice that, as time goes by, prices are constantly
changing, deals are being offered, and various promotions also
included.
Please send us a inquiry if you want to know much more
