65'' USB Multi IR Touch Screen For Gaming, POS, ATM, Lottery, And
Amusement
Infrared Touch Screen Working Principle:
Infrared Touch Screen is a touch frame which is usually installed
in front of the display screen. The frame is integrated with
printed circuit board which contains a line of IR-LEDs and photo
transistors hidden behind the bezel of the touch frame. Each of
IR-LEDs and photo transistors is set on the opposite sides to
create a grid of invisible infrared light. The bezel shields the
parts from the operation environment while allowing the IR beams to
pass through.
The Infrared Touch Screen controller sequentially pulses LEDs to
create a grid of IR light beams. When a user touches the screen,
enters the grid by a stylus which can interrupt the IR light beams,
the photo transistors from X and Y axes detect the IR light beams
which have been interrupted and transmit exact signals that
identify the X and Y axes coordinates to the host.
Advantages:
n 2points touch (Multi touch)
n Support zoom in/out, display rotation
n Withstands severe environments
n Stable, no-drift calibration performance
n Vandaproof and abrasion-resistant screens, ideal for rugged
applications
n Parallax-free performance for LCD displays
n Sealable against contaminants
n Operable in various light conditions, indoor and outdoor
Applications:
n Point-of-information kiosks , Desktop touch monitor
n Electronic catalogs, Ticket machine
n Gaming, POS, ATM, lottery, and amusement
n Industrial control rooms
n Computer-based training
n In-vehicles and transportation
n Medical instrument
Product Features:
1. Double-point write with peace,precise multi-point touching.
2. USB interface, Intelligent automatic calibration, drive-free and
maintenance-free.
3. Longevity of service ,maintenance free.
4. Aluminum alloy shell with strong stability.
5. Tempered glass with high light transmittance and true color
rendition.
6. Without driver ,supporting plug and play.
7. Adapt to internal and external linked environment.
8. No touching tools,no special touching pen is required ,only your
finger.
9. Fast response(less than 16 ms), no blind area, breakpoints, jump
points, pause and
other undesirable phenomena
Specification
| Size |
| General Size | 15 inch to 106 inch |
| Fit in with | Panel display device |
| Performance |
| Touch Mode | Single-point touch, Multi-touch, drag, draw-line, rotate, zoom
in/out |
| Resolution(Interpolation) | 4096*4096 |
| Linearity Error | <1.5mm |
| Response Speed | <15ms |
| Mechanical |
| Input Method | Finger or gloved hand (rubber ,cloth or leather) |
| Touch Times | Unlimited |
| Touch Activation Force | No minimum touch activation force is required |
| Minimum Touch Object | 2.5 mm X 2.5 mm |
| Vandal-proof | No break by 1-pound steel ball dropping from 130 cm high |
| Surface Durability | Surface durability is that of glass, Mohs' hardness rating of 7 |
| Optical |
| Glass: | Without glass, 4mm glare, AG (anti-glare), or AR (anti-reflective)
glass optional |
| Light Transmission | 92% |
| Gloss | Antiglare surface (curved or flat): 95 ± 15 gloss units or 65 ± 15
gloss units |
| Environmental |
| Temperature | Operating Range: -20°C ~ 70°C; |
| Storage Range: -40°C ~ 85°C |
| Relative Humidity | Operating Range: 0%~90% RH (no dew falls) |
| Storage Range: 0% to 95% RH (no dew falls) |
| Altitude | Up to 3,000m |
| Ambient Light | Direct sunlight 90°to ±30° to the display surface Touch detection
operational |
| Direct sunlight all angles to display surface Free of false touch
reports |
| Electrical |
| Operation Voltage | Typical +DC 5V, +4.75V to +5.25V |
| Power Supply | Size under 52”(include 52”)USB or PS/2 Interface, power ripple
max.200mV rms |
| Size above 52”(52” not included): external AC-DC power adaptor |
| Interface | Full Duplex USB 2.0 (Full Speed) Plug and play compatible |
| Serial RS-232. Baud Rate: 9600, 8 Data Bits, 1 Stop Bit, No Parity |
| Current | Typical 150MA@+5VDC; 350mA, maximum |
| Power | <1.5W, operating current<300mA |
| Electrostatic Protection | 15 kV air / 8 kV contact discharges (EN61000-4-2,1995 :Level 4) |
| Controller | Integration inside touch panel |
| Agency Approvals | CE, FCC, Rohs |
| Operating System |
| Operation System :windows 7 |
