    Metro Bus Station Wall Mount Lcd Display Advertising Screen 19 Inch RAM 1GB

    Ask Lasest Price
    Brand Name : ZXTLCD
    Model Number : ZXT-WB190A
    Certification : CE/Rohs/FCC/ERP Energy Label
    Price : Negotiate
    Payment Terms : T/T,Western Union, Alibaba trade assurance
    Supply Ability : 3,000 pcs per month
    Delivery Time : 10-12 working days
    • Product Details
    • Company Profile

    Metro Bus Station Wall Mount Lcd Display Advertising Screen 19 Inch RAM 1GB

    19 Inch Wall Mounted Metro Bus Lcd Android Network Wifi LCD Advertising Media Player

    All our products can be with the following four versions:
    *** USB version ad player: update advertisement by USB (Single Version)
    *** Network version advertising player: update advertisement through internet, support both Android OS and UCOS OS (Network Version)
    *** PC version kiosk(touch screen optional): its function is the same as computer, support OS of Windows7,windows8,windows XP,Linux,Apple etc. (Built-in PC Version,touch screen optional)
    *** Andorid OS4.2.2 kiosk(touch screen optional): kiosks using Android OS system.

    Our Solutions:

    Solution A. Single version

    Suitable for few qty of advertising player,need manually update the ads by inserting USB/SD card.
    simple to use and cheap

    Solution B. Anroid 5.1 RK3288

    Suitbable for many players to control to play the ads.
    Can install the apps,scan the webpage,etc. and add touch function.

    Solution C. PC version

    Acts like a PC.Can be installed the software and add touch function

    Network version advertising player: update advertisement through internet, OS: Android4.2.2(M158)

    Main hardware
    Board configuration
    CPU dual core ARM Cortex A9 1.5 GHz(max1.6GHz), Motherboard M158, GPU quad coreARM Mali-400 MP, HYNIX/SAMSUNG DDR3 1Gbyte, HYNIX/SAMSUNG NAND FLASH 8GB (Scalable TF/USB)
    Decoding resolution
    Perfect support 1080P Full HD
    Main function
    Programming
    Perfect support for video / picture / caption / logo / Date Time Day / weather, etc. regional free split-screen combinations; support background images
    Play Mode
    Receiving media content over the network, stored in the local loop after, commercials, broadcast regularly, gaskets playback;
    By U-import;
    U disk playback.
    Intelligent Management
    B / S architecture, GTV digital signage release management system(56IQ is optional software system): a custom template; timed release program, the program cycle play, schedule broadcast emergency announcements, gaskets and other players scheduled to play, MD5 two-way encryption, multi-level approval; terminal group management, real-time monitoring, remote control, timer switch, time to download, flow control; access control; logging and statistics functions
    C / S architecture, ADPE / EzPoster programming software: programming; schedule; Export card; two-way encryption; terminal timer switch and other functions
    Multimedia Support
    Supports MPEG1, MPEG2, MPEG4, H.264, WMV, MKV, TS, flv and other mainstream video formats; supports MP3 and other audio formats; Support JPG, JPEG, BMP, PNG, GIF and other image formats
    Basic interface
    Power Interface
    X1
    Video input interface
    VGA×1 HDMI×1
    Video output interface
    X 1,can directly drive 50 / 60Hz LCD, LVDS 30 core 2.0mm double needle
    Audio input interface
    X 1, linear input, 3.5MM headphone jack
    Audio output interface
    X 2,CLASS-D stereo amplifier output can directly drive 2 x 10W / 8Ω speakers, 2 core 2.0mm jack
    Ethernet Interface
    X 1,10 / 100M Ethernet
    WiFi interface
    X 1,WIFI(150Mbps)
    3G module interface
    PCIE slot (supporting a phone deck) x 1 ; USB interface x 1
    USB2.0 interface
    USB OTG x 1;USB HOST x 1
    Backlight interface
    X 1, 6 core 2.0mm jack
    RTC Real-Time Clock
    Time synchronization
    Watchdog reset
    Using an internal watchdog, abnormal automatic recovery


    Specification

    Product Name
    Android Network advertising player
    Size
    19inch/26inch
    CPU
    A20
    Mainboard
    A20
    RAM
    1GB
    ROM
    8GB
    OS
    Android 4.2.2
    Network
    Wifi
    Support
    * With our software,customer can manage and control all the players the ads by the software installed in the PC server.
    * Based on Android OS, network and wifi function are available, 3g/4g module is optional.
    How to use our Anroid network advertising player:
    1. Insert the USB dongle to PC to authorize this PC to install this software.Please close the firewall and some anti-virus software before installing the signage software.
    2. Connect the mouse with the player, to roll down the mouse to find register, then you can input the IP address of your server.
    If all players in one narrow network, you can just use any PCs to be server
    If players in different place, you need use the server with public IP, and all players can be connected with the server via public IP address

    3. Then you control the players by the software on PC
