32 Inch Wall Mount Touch Screen With Calendar Digital Signage
Advertising Sign Board
Description:
1,Outer shell is made by extra quality metal material, Color for
Outer Shell: Shinning Black.
2, With 3mm thickness tempered glass as protection layer against
the sureface of LCD screen.
3,Full New LG or Samsung ( Made in Korea) A Grade Stardard LCD
Panel.
4,Support SD card or USB port at one player; it is optional for VGA
Port, S-video port and HDMI port.
5,Safely locking system function to avoid flash memory card and
advertising playing contents being taken away, also can be
protected by password.
6, With USB update feature; support functions between the card and
card copying files (such as CF card to SD card,or SD to CF card
etc.); support U-copy, conveniently and quickly updating target
content, more details please visit user manual.
7,Playing advertising program automatically and circular; support
media format: JPEG (JPG), MP3, AVI, MPEG1, MPEG2, MPEG4, VOB and
DIVX (5.0/6.0).
8,Playlists support functions, can set different folders, copy all
target files to those different folders, system would default to
play your target file one by one.
9,Capable of setting rolling caption on the screen, playing rolling
caption in the advertisement program.
10,Build-in clock and calendar function in the system of player.
11,Support 5 groups of auto power-on/off timer, able to set those 5
groups of time one day and 7 days in one week.
12,Support shockproof and dustproof function.
| Specification |
| Panel parameter | Size | 32 inch LED screen |
| Display area | 698*392MM |
| Brand | LG/Samsung/auo |
| Resolution | 1920*1080 |
| Brightness | 350cd/m*2 |
| Color | 16.7M |
| Aspect ratio | 16:9 |
| Response time | 6.5MS |
| Contrast | 4000:1 |
| View angle | 178°/168°(H/V) |
| Mainboard | A20 |
| System Ram | DDR 128MB |
| System Rom | NAND FLASH 4G |
| IO connectors | 1 x USB host,1 x USB OTG,1 x serial Port,1 x I2C Interface,1 x LVDS
Interface ,1 x stereo Audio Out |
| Storage | USB/SD card |
| Decoding resolution | MAX 1080P |
| Audio | built-in HD audio 8(Realtek ALC888) audio system |
| Video format | MPEG1,MPEG2,MPEG4,H.264,WMV |
| Audio format | MP3 |
| Photo format | JPEG,BMP,PNG |
| OS | UCOS |
| OSD Language | Chinese, English |
| Play Mode | Supports loop playback, timed playback and other multi-player mode |
| Environment | Operating Temperature :0°C to 40°C
Storage Temperature :-20°C to 60°C
Humidity:20%-80% RH at 40°C, |
| System Power Supply | AC 110V~240V,50/60HZ |
| Power cord | Yes |
| TFT panel grade | Imported new panel |
| Case | Cold rolled steel with powder coating+ toughened glass surface |
Applications:
Business Organizations | supermarket, large-scale shopping malls, exclusive agency, chain
shops, large-scale sales, star-rated hotels, restaurants, travel
agencies, pharmacy. |
Financial Organizations | Banks, negotiable securities, funds, insurance companies,
pawnshops; Non-profit Organizations: Telecommunications, post offices,
hospital, schools; |
Public Places | subway, airports, stations, gas stations, toll stations,
bookstores, parks, exhibition halls, stadiums, museums, convention
centers, ticket agencies, HR market, lottery centers; Real Estate
Property: Apartments, villas, offices, commercial buildings, model
rooms, property brokers; |
Entertainments | Movie theaters, fitness halls, country clubs, clubs, massage rooms,
bars, cafes, Internet bars, beauty shops, golf course |
Shipping
2. Delivery Ways:
a. By Express ( DHL / UPS / TNT / Fedex for option), it takes about
4-9 working days
b. By Air: It will takes 5-10 days
c. By shipping. It will takes 15-35 days (according the place of
your local port)
3. Leading Time:
a. Sample: 7-15 working days ( For standard products)
b. Bulk order: 10-35 working days ( According the quantity)
c. Customized Products
1) Design Structure: 20-35 working days
2) Sample: 15-20 working days
If you have any other questions, please contact our salesman as
soon as possible.
